R12 DB Chuan Carbon Road Bike Frameset
The Yoeleo R12 DB Chuan road bike frameset delivers race-level performance with UCI approval and advanced aerodynamics. Built from high-modulus Toray 800 carbon fiber, it offers an ideal balance of stiffness, responsiveness, and comfort. Designed for both Di2 and mechanical groupsets, this lightweight disc-brake bike frame supports up to 32 mm tires with fully internal cable routing for a sleek, pro-level finish.
UCI Approved: Yes
Frameset: R12 Frame+Fork+Handlebar+Seatpost
Frame Sizes: 43cm,47cm,50cm,52cm,54cm,56cm,59cm
Handlebar Size: 380mm,400mm,420mm,440mm
Stem Size: 90mm/100mm/110mm/120mm
Material: High Modulus Toray 800 Carbon Fiber
Carbon Weave: UD
Groupset Compatible: Machine and Di2 compatible
BB: BB386
Rear Dropout: 12*142 Thru Axle
Rear derailleur hanger: Replaceable
Headtube: 1-1/2” Straight
Fork: Aero Disc Brake Fork,Flat Mount,12*100 Thru Axle
Fork Offset: 45˚
Brake: Flat Mount Disc Brake
Max Tire Width: 32mm
Cable: Internal cable
Frame Weight:
Chuan 1030g (47cm) +/-50g
Fork Weight: 400+/-10g
Accessories: Handlebar Spacers 3mm: 1PC, 5mm: 1PC, 10mm: 2PCS, Headset Bearing Cap 10mm: 1PC, Front Axle 1PC, Rear Axle 1PC
Limited Rider Weight: 110KG
Warranty: 6 Years
Warranty
Standard Coverage: 6-year warranty
Crash Replacement Policy
YOUR SAFETY MATTERS
While we sincerely hope you won't require it, we provide a 30% crash replacement discount on all handlebars and spares in the unfortunate event of a crash. Reach out to us, and we'll strive to assist you promptly, ensuring you can get back on the road and ride again as soon as possible.
Ride Like The Wind
This frame is all about turning your hard work into fast rides. It's built to make sure every push on the pedals moves you forward, quickly.
Whether you're climbing up a hill or speeding down one, you'll feel as sharp and confident as a pro racer. It's perfect for cyclists who want to get the most out of every ride, making sure you're always ahead of the pack.
ProMoldCore Technology
The conventional manufacturing method that is still common practice with most companies today brings a lot of issues. Conventional methods causes undulations on the internals of the frame and even increases weight, making it difficult to achieve performance according to the specified carbon sheet specifications. Unlike traditional methods such as nylon bladders, ProMoldCore manufacturing technology allows for a more stable molding of the inside of the frame thanks to latex's flexibility and stretchability. We believe that inside out beauty applies for everything, especially for our framesets. By utilizing ProMoldCore technology, the outside and inside of a carbon road frame are of the same quality, resulting in an inner surface that is as smooth and wrinkle-free as the outer surface.
Frameset Geometry
